JBL SRX725/F REV PACKAGE WIRING DIAGRAM 07-14 Technical Manual JBL SRX725/F SPECIFICATIONS ACOUSTIC & ELECTRICAL SPECIFICATIONS: • Nominal Impedance: 4 Ohms • Power Capacity: Continuous Program / Peak: Passive: 1200W / 2400W / 4800W Bi-amp L.F: 1200W / 2400W / 4800W Bi-amp H.F: 75W / 150W / 300W • Frequency Range: 37 Hz - 20 kHz (-10 dB). LF Driver: 2 x JBL 2265H 380 mm (15 in) Differential Drive woofer with neodymium-magnet and dual voice-coils HF Driver: 1 x JBL 2451H 102 mm (4 in) voice-coil, neodymium-magnet compression driver Nominal Impedance: Passive: 4 ohms Bi-amp LF: 4 ohms Bi-amp HF: 8 ohms Active Tunings: dbx DriveRack, all models. Settings available at www.jblpro.com
Which amp for SRX 725. I have the speakers tunings all set per JBL The 2 15's in the 725 used as lows are high passed at 93.6 the 718's are hpf at 31.5 and lpf at 88.5 per JBL tunings. Sorry for calling them mids. « Last Edit: February 22, 2011, 04:26:57 PM by Brian Wilkinson ». For the ultimate in performance and simplicity, a pair of SRX725s and a single, high-power amplifier delivers superb high-level music and powerful bass. A pair of JBL 2265H Differential Drive drivers handles an amazing 1200 watts of continuous power. The 2452H 4" compression driver, respected worldwide as one of the finest high-powered transducers made, provides smooth, clear mids and highs.
